LED Full Color Display P1.25 P1.875 P2 P2.5 P3 P1.5 Small Pitch
Advertising Screen Indoor
Continues Quality
With more than 10 years experience in led display
producing,equipments are updated regularly.What’s more,unique
standardized and module production ensure our products continuous
quality.
Competitive Price
With large scale production capacity and professional production
technology,our company have built effective modular production.We
always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill
it.Special procedures such as emergency inventory will be used to
maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and
we’ll recommend suitable products to you. After-sales:We will track
the products usage and then constantly perfect our products.
Details
1. Modular design for quick installation and removal
2. Highly reliable data hot backup, avoiding any communication
risks during the exhibition
3. High refresh rate up to 4200Hz, and live video without flashing
at all
4. Super brightness and color uniformity, pixel calibration before
leaving the factory
5. Horizontal / vertical viewing angle up to 120° uniform HD
display, no color cast, no color spots, no color blocks
Description:
Template Size: 256mm*128mm | Template resolution:128*64 |
| Color: full color | Cabinet size: 512*512mm |
| Maximum power: 850W | Light: Amd1515 black light |
| Drive mode: 1/32 scan constant current | Guarantee: 2 years |
| Lifetime:>100,000 hours | Refresh rate:≥1200Hz |
Application:
Full color screens are widely used in government and enterprise
projects, exhibitions, cultural tourism, commercial real estate,
outdoor advertising media and other fields. For example:
supermarkets, restaurants, travel agencies, commercial plazas,
cinemas, clubs, schools, hotels, hospitals, communities, commercial
buildings, subway stations, airports, etc.
In short, many places need led screens for various purposes, we
will do our best to meet trends and needs.
Specification (parameter):
| SHENZHEN JINGCAIYUAN TECHNOLOGY CO., LTD |
|
| P2 SMD 3 IN 1 TECHNICAL PARAMETERS |
|
| Unit Module | Item | Parameter |
| Model Number | P2-32S |
| Module size | 256mm*128mm |
| Pixel pitch | 2mm |
| Pixels Density | 250000 dots/m2 |
| Pixel configuration | 1R1G1B |
| Package mode | SMD 3IN1 -1515 |
| Pixel resolution | 128dots(W)*64 dots(H) |
| Max Power | 23W |
| Module thickness | 13mm |
| Weight | 0.352KG |
| Drive type | Constant drive |
| Scan mode | 1/32scan |
| Port type | HUB75E |
| Brightness of white balance | ≥800cd/㎡ |
| LED Cabinet | Dimension | 512mm*512mm |
| Monomer Module Number | 16pcs |
| Power supply | 5V/40A*1 pcs |
| Pixel per cabinet | 256*256 |
| Best viewing distance | 2M～10M |
| Best viewing angle | 140°(W) 120°(H) |
| Temperature | storage:-35℃～+85℃ |
| working:-20℃～+50℃ |
| Relative humidity | 10%-95% |
| Thickness | 65mm |
| Power | Working voltage | AC220V±10% |
| Average Power consumption | <280W/㎡ |
| Max.Power consumption | <700W/㎡ |
| Current | <15mA(single LED) |
| Control system | CPU | Pentium4 or above |
| Operation system | WIN98/2000/NT/XP/WIN7/WIN10 |
| Control method | Synchronization |
| Main technical parameter | Driving device | Constant drive IC |
| Refresh frequency | >1920HZ |
| Grey scale/colors | 65536, can display 16.7M color |
| 65536gray level/16.7M colors |
| MTBF | >9000hours |
| Power switch | Automatic switch |
| Display Mode | ≥1024*768 |
Competitive advantages:
- Installation service, usually we are not responsible for overseas
installation, but we can provide technical support for you. If you
need this, we can arrange our technicians to your country, but the
cost is paid by the customer.
- Free lifetime maintenance and software upgrades.
- If you have any questions about the led display, we will reply you
within 24 hours, and provide maintenance instructions and problem
resolution within 48 hours.
- Providing customers with loaders so they can use the display
immediately after installation
- Led display, no need to debug
- Free technical training about how to use and process software.
