P3 indoor rental LED display full-color 500x500mm cabinet 1200cd
brightness
Indoor Full Color LED Display Function:
1. The excellent visual effect, better viewing effect for text and
graphic or video
2. Large viewing angle, both H/V can reach 110 degrees; getting
vivid effect within any position of the viewing range;
3. High contrast ratio and good evenness, high uniformity, without
mosaic
4. Resist of the high temperature and antioxidation and
anti-static;
5. Any led in each pixel can be respectively replaced, which
reduces the cost of the display maintenance.
6. Long using life & MTBF
Description:
| Asphalt: | 3mm | Module size: | 192X192mm |
| Cabinet size: | 576x576mm | Display function: | Video |
| Mode driver: | 1/32s | Pixel density: | 111111dots/ m2 |
| Pixel: | 64 * 64dots | Brightness: | ≥1200cd |
Details
1. Modular design for quick installation and removal
2. Highly reliable data hot backup, avoiding any communication
risks during the exhibition
3. High refresh rate up to 4200Hz, and live video without flashing
at all
4. Super brightness and color uniformity, pixel calibration before
leaving the factory
Application:
Full-color screens are widely used in government and enterprise
projects, exhibitions, cultural tourism, commercial real estate,
outdoor advertising media, and other fields. For example
supermarkets, restaurants, travel agencies, commercial plazas,
cinemas, clubs, schools, hotels, hospitals, communities, commercial
buildings, subway stations, airports, etc.
In short, many places need led screens for various purposes, we
will do our best to meet trends and needs.
Specification (parameter):
| Pixel pitch | 3mm |
| Pixel configuration | 1R1G1B |
| LED type | 3 in 1 SMD 2121 |
| Module size | 192x192mm |
| Module weight | 0.35kg |
| Module resolution | 64x64dots |
Cabinet parameters:
| Cabinet size | 576x576mm |
| Cabinet material | Die-cast aluminum |
| Cabinet weight | 7.5kg |
| Cabinet resolution | 192x192dots |
| Protection level | Front and rear IP65 / IP54 |
Full screen parameter:
| Pixel density | 111111dots/m² |
| Brightness | ≥1200cd /m² |
| Viewing angle | H≥120° V≥120° |
| Minimum viewing distance | 3m |
| Maximum power consumption | 890W /m² |
| Average power consumption | 330W /m² |
| Operating Voltage | 110〜220VAC±15％ |
| Interface | HUB75 |
| Color | 16.7millon colors |
| Gray scale | 65536 |
| Refresh rate | ≥1920Hz |
| MTBF | ≥50000hrs |
| Lifetime | ≥100000hrs |
| Operating temperature | -10℃〜+ 60℃ |
| Storage temperature | -20℃〜+ 60℃ |
Control system parameters:
| Video signal (with video processor) | AV,S-video,VGA,DVI,YPbPr,HDMI,SDI,DP |
| Color temperature | Adjustable by software |
| Brightness level | 256 levels, automatically adjusted by software |
| Control way | Computer, video sync, real time, offline, internet, etc. |
Competitive advantages:
- Installation service, usually we are not responsible for overseas
installation, but we can provide technical support for you. If you
need this, we can arrange our technicians to your country, but the
cost is paid by the customer.
- Free lifetime maintenance and software upgrades.
- If you have any questions about the led display, we will reply you
within 24 hours, and provide maintenance instructions and problem
resolution within 48 hours.
- Providing customers with loaders so they can use the display
immediately after installation
- Led display, no need to debug
- Free technical training about how to use and process software.
